​Blue Mountain Manufacturing, INC

PO Box 452

54182 HWY 74

​Heppner OR 97836

rb-2


Capacity: 4,000lbs

Features: 6) 32" Miller Spikes, and two hydraulic cylinders.

Options: 49" Miller Spike Upgrades

ROUND bales


LD-5


Capacity: 600lbs

Features:  Metal Bushings, mild steel shafts, 10 small hooks, and hydraulic cylinders.

Sd-10


Capacity: 1,500lbs

Features:  Metal bushings, mild steel shafts, 24 small hooks, and hydraulic cylinders.

Options: 105 degree rotator, high reach arch, and arch rotator combo. (options shown on the CD-10, and HD-10)

CP-2h


Capacity: 4,000lbs

Features:  Plastic Bushings, alloy shafts, 24 large hooks, hydraulic cylinders, 90 degree horizontal to vertical rotation.

Options: Additional Hooks

TG-3


Top Grab

Capacity: 3 Mid Sized Bales

Features:  Plastic Bushings, alloy shafts, 12 large hooks, hydraulic cylinders

Options: Additional Hooks

SF-2


Capacity: 4,000lbs

Weight: 500lbs

Features:  Forged Spikes

Options: Spike upgrade, 4x4 top with spike sockets

vt-1


Capacity: 2000lbs

Weight: 540lbs

Features:  Plastic bushings, alloy shafts, miller spikes, 6 large hooks, hydraulic cylinders

Options: Extra large hooks, additional hooks, spike upgrade, forged spikes.

vt-2/vm-3

VM-3

Capacity:  4000lbs

Weight: 900lbs

Features: Designed to pick up three, 3x4 bales.

**looks the same as the VT-2, Options are the same as the VT-2

VT-2

Capacity: 4000lbs

Weight: 850lbs

Features:  Plastic bushings, alloy shafts, miller spikes, 10 large hooks, and hydraulic cylinders.

Options: Extra large hooks, larger spikes, forged spikes, 4x4 top with spike sockets.

Bale Forks


Our bale forks are built with quality materials, with replacement hooks, and spikes in stock.  You never have to worry about breaking one again.



LARGE BALES

hd-10


Capacity: 2,500lbs

Features:  Plastic Bushings, solid steel shafts, 40 small hooks, and hydraulic cylinders.

Options: 105 degree rotator, high reach arch, and arch rotator combo (shown on the CD-10) additional hooks, heavy duty plastic bushings, and larger hooks.

cd-15


Capacity: 2,500lbs

Features:  Metal bushings, alloy shafts, 3 small hooks, 2 hydraulic cylinders.

Options: Plastic bushings, additional hooks.

Small bales


cp-2v


Capacity: 4,000lbs

Weight: 1200lbs

Features:  Plastic wear components, alloy shafts, 12 large hooks, miller spikes, hydraulic cylinders, 90 degree horizontal to vertical rotations.

Options: Spike upgrade, forged spikes, additional hooks.

​Toll Free: 1-800-827-8257

Phone: 1-541-676-5472

​Fax: 1-541-676-9428

​Email: sales@millerforks.com

© 2014 Blue Mountain Manufacturing, INC

CD-10


Capacity: 2,500lbs

Features:  Metal Bushings, solid steel shafts, 32 small hooks, and two hydraulic cylinders

Options: 105 degree rotator, high reach arch, and arch rotator combo
